MSS SP-71 Class 125 Cast Iron Air Cushion Swing Check Valve

Product Description

Why to add this cylinder?

With an external cylinder, when the valve disc quickly closes but there is still 30% left to close, the cylinder begins to work, causing the valve plate to slowly close. This can prevent the medium in the pipeline from quickly accumulating pressure and damaging the pipeline system

Why to add the weight block?

Equipped with a weight block, it can quickly close in the pipeline and eliminate destructive water hammer

MSS SP-71 Class 125 Cast Iron Air Cushion Swing Check Valve is a cast iron air cushion swing check valve that also complies with the American Standard Manufacturing Society (MSS) standard SP-71 and is rated Class 125. The following are the features, benefits and uses of this valve:

Advantage:

Reduce water hammer: The air cushion design can effectively reduce water hammer and vibration, improving the stability and safety of the pipeline system.
Long-term reliability: Cast iron material has good corrosion resistance, ensuring the reliability of the valve in long-term use.
Automatic operation: According to the flow conditions of the medium, the valve can automatically open or close without manual operation.

Usage: MSS SP-71 Class 125 Cast Iron Air Cushion Swing Check Valve is mainly used in industrial piping systems, especially in those situations where the flow of media fluctuates greatly, easily causing water hammer and vibration. Common application areas include water supply systems, sewage treatment systems, industrial manufacturing and chemical processes. This kind of valve can effectively protect the pipeline system, ensure stable flow of media, reduce the stress and loss of the pipeline system, and improve the safety and reliability of the system.
